cvchess-in-browser

Prompt

Build a browser-based computer vision app that extracts the state of a chess board from a photo of a physical board taken from an oblique angle, in the spirit of jayhack/CVChess (CS231A, 2014) — except everything runs inside the browser window, with no server-side inference.

The boards in the wild are not flat overhead shots. Expect what you'd see in tournament photos, living-room shots, and product listings: slanted perspectives, tilt, cropping, varied lighting and board styles. The algorithm must handle oblique views, not just top-down boards. That almost certainly means detecting the four board corners (or the board outline) and applying a homography to rectify the 8×8 grid before classifying squares.

What the agent is being asked to do

This eval is not only about shipping code — it's about iterating on a CV algorithm against a real dataset and then writing up the result.

Concretely, the agent must:

1. Assemble an evaluation dataset of chess-board photos from publicly available sources (e.g. Google Images search for things like "chess board from above", "chess game tournament", "chess set on table"). At least 8 images, spanning a range of:
   • camera angles (closer to top-down ↔ strongly oblique),
   • board styles (wood, vinyl, tournament, digital/e-board, themed sets),
   • lighting conditions / photo quality. Save the images inside the solution and record the source URL / attribution for each one in a dataset.json (or similar) that also stores, per image, the expected board state or occupancy when feasible (full starting position, a known midgame, empty board, etc.), so the agent can actually score itself.
2. Build the CV pipeline and iterate on it: run it against the dataset, inspect failures, adjust parameters / heuristics / models, rerun. The final submission should reflect that loop — not a single guess.
3. Write up the result in the UI so a reviewer can see what the algorithm does and how well it works, not just poke at a demo.

Deliverable: one HTML with three tabs

Ship one self-contained, browser-runnable web page inside the solution directory (usually index.html, optionally with sibling JS/CSS/model/image files). The page must be organized as three tabs:

Tab 1 — Demo

A working CV app:

• Input selection: either upload an image (file picker and/or drag-and-drop) or pick one from the shipped evaluation dataset (the gallery doubles as a "search images" affordance).
• Pipeline runs in the browser (JS / WebAssembly / WebGL / WebGPU / canvas — anything client-side). OpenCV.js, TensorFlow.js, ONNX Runtime Web, MediaPipe, pure-JS CV are all fair game. Heuristic approaches and learned classifiers are both welcome, as long as any model weights ship inside the solution and inference happens client-side.
• Visualization: the detected board (corners + rectified grid) drawn over (or beside) the input image, with per-square classification.
• Readout: a board-position readout — FEN string, an 8×8 grid of labels, or a rendered chess diagram — so a reviewer can compare the extraction against the input photo.
• Progress/feedback while the pipeline runs (spinner, stage markers, etc. — this isn't instant on a phone photo).

Tab 2 — How it works

An explainer of the algorithm itself, with graphics. Not a dry wall of text. Walk the reader through the pipeline stage by stage — e.g. edge / line detection → board-corner localization → homography / rectification → square segmentation → per-square occupancy/piece classification → FEN assembly. For each stage, show what's actually happening:

• annotated images from the dataset (with detected edges / corners / grid / per-square crops drawn in),
• short diagrams or animations where they help,
• a few lines of math or pseudocode where they clarify the step.

A reader should leave this tab understanding how the pipeline works end-to-end, not just what the buttons in the demo do.

Tab 3 — How well it works

An analysis of the algorithm's performance on the evaluation dataset:

• Run the pipeline on every dataset image and report results — per-image board-level score (correct occupancy, correct FEN, etc.) and aggregate metrics (overall accuracy, per-stage success, something like confusion of "empty vs. occupied").
• Call out where the algorithm fails with concrete examples from the dataset (which image, which stage, why).
• Honest framing: which angles / board styles / lighting conditions it handles well, which it doesn't, and what would be needed to close the gap.
• Precomputed tables/charts are fine; so is re-running the pipeline in-browser on the dataset when the tab opens, as long as it terminates in a reasonable time.

Deliverable checklist

Commit inside the solution directory:

• The entry HTML (and any sibling JS/CSS/model files it needs).
• The evaluation dataset of at least 8 images (plus a dataset.json-style manifest with source URL, attribution, and — where possible — ground-truth board state / occupancy).
• Any model weights, classifier files, or precomputed results the pipeline or analysis needs, so the app works offline after page load.

Opening the deliverable in a modern desktop browser must be enough — no backend, no API key, no build step before a playable HTML exists. Serving the directory with python -m http.server (or similar) is allowed if the browser's file:// protocol blocks local fetches.

Acceptance criteria

A submission passes if a fresh evaluator can:

1. Clone the repo, cd into the solution directory, and follow the solution README.md.
2. Open the committed HTML (directly or via one documented static-file-server command) and see the page load with three visible tabs: Demo, How it works, How well it works.
3. On the Demo tab:
   • Pick an image from the shipped dataset (≥ 8 images, covering a range of oblique angles, board styles, and conditions) and see the pipeline detect the board, show per-square classification, and emit a board-position readout.
   • Upload their own oblique-angle chess-board photo and see the same pipeline run end-to-end on it, fully in the browser (network tab should show no inference calls to a remote server).
4. On the How it works tab, read a graphics-driven explainer that walks through the pipeline stage by stage with annotated images from the dataset.
5. On the How well it works tab, see per-image results and aggregate metrics on the shipped dataset, plus an honest discussion of failure modes.
6. Get reasonable results on a majority of the dataset images — the board should be detected on most oblique-angle photos and empty-vs-occupied should be roughly right. Piece-type recognition is a plus but not required for the submission to pass.

Results site — artifact button

So the results site shows Open HTML output and Open artifact for your submission, mirror the playable file and register it:

1. Copy the entry HTML (bundled or with its sibling assets) to docs/artifacts/cvchess-in-browser/<harness>-<model>.html (same name as your solution folder under this eval). Inline or fetch sibling assets as needed so the mirrored file still works when opened from docs/artifacts/….
2. On your solution object in docs/data.json, set "artifactUrl": "./artifacts/cvchess-in-browser/<harness>-<model>.html".

See the repo root README — HTML artifacts for the full convention.

Out of scope

• Running inference on a remote server or proxying to a hosted vision API — the whole algorithm must execute in the browser.
• Live webcam capture (a single still image per run is fine; webcam is a nice bonus, not a requirement).
• Move legality, chess engines, PGN history, or game-play. This eval is only about extracting a static board position from an image.
• Mobile-first UX, multiplayer, accounts, persistence.
• Datasets dominated by overhead / top-down shots only. Oblique-angle coverage is the point.

Notes for evaluators

Think of this as CVChess restaged as a browser tool with a real eval loop on top of it. The interesting questions are:

• Does the board actually come out on oblique photos? Not just flat overhead shots.
• Did the agent iterate? The "How well it works" tab should show that the algorithm was actually run against the assembled dataset and the results looked at, not just hand-waved.
• Is the explainer legible? "How it works" should teach the reader something, with graphics, rather than restating the prompt.
• Is it really in-browser? No server inference, no hidden API calls.
• Is the demo UI legible? Upload + gallery, overlay, and a readable board-position readout.

Solutions: <harness>-<model>/ under this folder.
